Strong Points

Frame with fix 3PH
Gearbox with grooved belt
Pivoting rear wheels
Hydraulic lower feeder
Feeding rakes

General description

Mowers with pick-up are machines destined to the mulching of pruning material on vineyards. They have a special rotor that allows to work at very high speed. Thanks to its perfectly positioned and dimensioned pick-up, a very stable and uninterrupted feed is achieved. They are also very manageable and compact. All these details make them the fastest and most efficient pruning mowers on the market today.

More information

Technical information

Standard equipment

  • Transmission driven by belts (XPB)
  • Chassis with fixed head
  • Front protection plates
  • Gearbox with free wheel (1″3/8 – Z6)
  • Replaceable counter-blades
  • Rotor Ø412 with oscillating hammers
  • Feeding rake
  • Rear directional wheels
  • PTO Bondioli G5
  • Rastrillo para alimentación
  • Ruedas traseras direccionales
  • Toma de fuerza Bondioli G5
Reference Description Ø Cut
Rotor
X L W H
mm m mm kg Hp mm mm mm
TD-VID-110 “PICK UP”
mower for vineyard
16 412,3 1,1 : 567 694 40 1400 1860 1227
TD-VID-130 18 412,3 1,3 : 667 771 50 1600 1860 1227
TD-VID-150 22 412,3 1,5 : 767 852 70 1800 1860 1227
TD-VID-180 26 412,3 1,8 : 917 978 80 2100 1860 1227

Some accesories

Control for simultaneous use of flail mower with hydraulic pick-up and wood sweeper

Lateral flaps

Mechanical feeder

Hammer
