Strong points

Hydraulic power unit of 30L
Floating and tilting system
Electro hydraulic in row weeders
“2 in 1” Radial and parallelogram system in row weeders
Multiples accessories available for both radial and parallelogram movement
Double hydraulic cylinders with synchronized extension, without joints and mechanisms
Strong frame and robotic welding
Adjustable self-supporting height sensor

General description

FRONTAL CHASSIS

Chassis coupled directly in the front of any tractor(without three point hitch), it is an ideal equipment for weed control between plants (e.g. vineyard and orchard) formed in rows. Equipped with 1 o 2 electro hydraulic in-row weeder , commanded by a hydraulic power unit and controlled by a control box installed in the tractor cab. It has been developed to work around the plant even with a very small size (from 1 cm diameter of plant trunk). The use of different tools is possible, allowing both surface works without earth removal and deep works up to a working  depth of 20 cm. The equipment is controlled by an adjustable sensing rod, equipped with an electronic inductive sensor. The system combines a parallelogram displacement with a radial movement, that provides the equipment an high accuracy and at the same time an high tolerance allowing deviations higher than 30 cm in the plants line, or in the tractor trajectory. Allows working speeds up to 12 km/h.

More information

Technical information

Standard equipment

  • Electric controls in cabin
  • Anti-shock sensor protector
  • Hydraulic pressure regulator
  • Electro hydraulic in row weeder
  • Hydraulic extension to the tractor
  • Floating elevation cylinder
  • Tool kit for sensor regulation
  • Arm “D” and Plough blade to weed manufactured in boron steel
  • Quick connect kit for power tools
  • Special testrod sensor in high tensile steel
  • Adjustable pair of metal wheels in height and width
  • Independent hydraulic power unit 30L (C1)
  • Storage foot
  • Adaptable standard plate to tractor (frontal)

Reference

Description

L

W

H

cm

m

Kg

Hp

m

m

m

CF-XS-IAC-D

Front chassis Extension/Elevation Direct tractor

1 In row weeder

Mini

49

≥ 1,45

550

35

1,30

0,80

1,35

CF-S-IA-D

Small

≥ 1,85

600

35

1,15

1,06

1,35

CF-M-IA-D

Medium

55

≥ 2,45

715

40

1,15

1,55

1,35

CF-L-IA-D

Big

≥ 3,00

750

45

1,15

2,10

1,35

CF-XS-IAC-P

Front chassis Extension/Elevation Direct tractor

2 In row weeder

Mini

49

1,45 – 1,85

600

40

1,30

0,90

1,35

CF-S-IA-P

Small

1,45 – 2,00

650

40

1,15

1,30

1,35

CF-M-IA-P

Medium

55

2,45 – 3,20

765

45

1,15

1,90

1,35

CF-L-IA-P

Big

3,00 – 4,10

800

50

1,15

2,40

1,35

Some accesiories

Standard oil cooler

Disc harrow without motor to cover

Blade shovel to weed

Arm adjustable shovel

Reversible mini disc harrow

Soil and stone deflector

Rotary hoe

Blades mowers

Rotary brush

Herbicide application head

Pair of front neumatic wheels

Remote control cable
